Enertex® ViTa KNX Präsenzmelder
Compatible with single or double rocker, radar-based presence and motion detector, humidity sensor, temperature sensor, light sensor, two external inputs, eight logic functions
Enertex® AluRa, JUNG Serie A/AS
Order number: 1181-02-AR
JUNG Serie LS
Order number: 1181-02-LS
Features
- Built-in temperature and humidity sensor
- Integrated light sensor
- Presence detection with evaluation of vital movements (breathing, sitting still) up to 3 m
- Alarm for motion detection with filter and time window function
- Three separately configurable channels for motion/presence detection
- Counter for incoming and outgoing movements (people counting in passage areas) as well as differential counting
- Supports up to eight logic functions
- Built-in bus coupler for power supply via the KNX bus (no additional power supply required)
- KNX Data Secure
- Mechanical push-button sensor for a single or double rocker
- Rockers optionally usable as individual push-buttons
- Functions for switching, dimming, colored light control, blinds control, value generation, scene recall
- Directional motion detection via radar-based motion sensor with up to 10 m range in 3 zones
- Presence detection up to 6 m
- Two external binary inputs, optionally usable for an external temperature sensor (e.g., Albrecht Jung item no.: FF NTC)
- Compatible with standard flush-mounted boxes
Specific features for order number 1181-02-AR
- Compatible with Albrecht Jung Series A
- Compatible with Enertex AluRa (Enertex item no. 1178-xx-xx)
- Compatible with Jung frames (Albrecht Jung item no. AC 581 xy, AV 581 xy, AS 581 xy, A 5581 xy)
- Compatible with single rocker, Albrecht Jung item no.: A 101 KO5 or single rocker Albrecht Jung item no.: A 101 xy for single rocker operation
- Compatible with double rocker, Albrecht Jung item no.: A 102 KO5 or double rocker Albrecht Jung item no.: A 102 xy for double rocker operation
Specific features for order number 1181-02-LS
- Variant 1181-02-LS fits JUNG LS series
- Compatible with JUNG LS frames (JUNG item no.: LS 981 xy, LSD 981 xy, LSP 981 xy, LS 581 xy)
- Compatible with single rocker: JUNG LS 101 xy without viewing window or LS 101 KO5 xy with viewing window (dome)
- Compatible with double rocker: JUNG LS 102 xy without viewing window or LS 102 KO5 xy with viewing window (dome)
- xy denotes the color/finish code
Downloads
| ZIP | ETS Product | 3.0, 05.11.2026 |
| ZIP | Firmware | 3.006, 09.11.2026 (→ Update Tool) |
| User Manual | 15.07.2026 | |
| CE declaration of conformity |
| Flyer | 05.03.2026 |
